Conductor Material CCA(Copper content 22%–31%) Diameter 0.57 mm ± 0.01 mm American Wire Gauge 23AWG Insulation Material HDPE Min. Average Thickness 0.21 mm Diameter 1.02 mm ± 0.06 mm Color (4 Pairs) Blue, white/blue; orange, white/orange; green, white/green; brown, white/brown Separator Material PE Specification Translucent 4.5 × 0.4 mm Rip Cord Material Polyester Specification 500D Sheath Material PVC Min. Average Thickness 0.5 mm Diameter 6.5 mm ± 0.3 mm Color Orange Electrical Max. DC Resistance of a Single Conductor 11.5Ω/100 m Min. Insulation Resistance 5000MΩ·km Max. DC Resistance Unbalance 2% (pair intra), 4% (pairs inter) Dielectric Strength No breakdown with 1KV DC for 1 min Transmission Characteristic Impedance 100 ± 15Ω Near End Cross Talk ≥39.30 dB/100 m@250 MHz Max. Attenuation 34.8 dB/100 m@250 MHz Return Loss ≥17.3 dB/100 m@250 MHz Mechanical Tensile Strength Sheath≥13.5 MPa, insulation≥16 MPa Elongation at Break Sheath≥150%, insulation≥300% Installation Bending Radius >8 times of outer cable diameter Conductor Elongation at Break ≥10% Environmental Shrinkage of Insulation ≤5% Color Migration Resistance of Insulation No migration Sheath Tensile Strength and Elongation at Break after Aging ≥12.5 MPa, ≥100% Low Temperature Bending Test No cracking after the test Heat Shock Test No cracking after the test Operation Temperature –20°C to 60°C (–4°F to 140°F) Installation Temperature 0°C to 50°C (32°F to 122°F) Storage Temperature and Humidity –10°C to 40°C (14°F to 104°F), <60% (RH) Security Vertical Fire Propagation Test Comply with IEC 60332-1-2 Packaging Length 305.0 m (1000.66 ft) ± 1.5 m (4.92 ft) Packaging Dimensions 390.0 mm x 390.0 mm x 247.0 mm (15.37″x15.37″x9.73″) (L × W × H) Packaging Method 305.0 m (1000.66 ft) a carton, one protection carton with 2 cartons inside Net Weight ≥9.2 kg (20.28 lb) Gross Weight ≥10.2 kg(22.49 lb) Executive Standard Executive Standard Q/DXJ 067-2019 Certification Certification CPR Eca SKU: DH-PFM922I-6UN-C-V2 Categories: Cables, CCTV & Antenna Cables, Data Cables
