General Data Standards Compliance IEC 60898 Warranty 10 Years from the Date of Selling Protection Protection against both overload and short circuit Technical data Rated Voltage AC 230/400V Rated current 6A/10A/16A/20A/25A/32A/40A/50A/63A Rated frequency 50/60Hz Number of Poles 2POLE Rated Short Circuit Capacity (Icn) 10000 A Conventional Tripping Current 1.13In ≥ 1h Conventional tripping current 1.45In < 1h 2.55In 1S < t < 60S for In <32A 1S 32A Instantaneous tripping type Type C Instantaneous tripping current 10In Instantaneous non tripping current 5 In Electro-mechanical endurance 4000 Cycles Degree of protection IP 20 Connection capacity 25mm2 Fastening torque 2 Nm Ambient Temperature -5ºC to 40ºC DIN rail Easy mounting on 35mm DIN rail Mounting feature in Flush Type Adjustable type DIN rail mounting Mounting Type Rail plug in Connecting Type Clamping terminal External Dimensions (L*W*H) mm 78*36*81 Material Plastic Poly Amide Metal Phosper Bronze, Brass, Zinc plated steel SKU: N/A Category: 1 Pole
